Applications
Trailers & Containers
Construction Equipment
Heavy Machinery
Generators & Pumps
Pharmaceutical Transport
Refridgeration Trailers
Mobile Storage Units
Cold Chains
Specifications
Connectivity
Cellular
LTE Cat-M1 & NB2 (NB-IoT)
2G Fallback
GPS
Multi-constellation GNSS (GPS, BEIDOU, GLONASS, GALILEO, AGPS) with <2m accuracy
Bluetooth
BLE 5.0
Inputs
1 Analog Input, 5 Digital Inputs
Outputs
4 Open Drain Outputs
Physical
Dimensions
Φ138mm L x 66mm W x 38mm H
Φ5.43in L x 2.60in W x 1.50in H
Weight
320g (11.29 oz)
Operating Temperature
-30°C to +80°C (-22°F to +176°F)
IP Rating
IP67
Installation
Screw/Bolt
Sensors
3-Axis Accelerometer
1-Wire Temperature Sensor
Serial Port
RS232
Power
Battery Life
120 Days Standby
Operating Voltage
DC 8V to 32V
Battery Type
5800 mAh lithium batteries
2 x 18650 Li-ion
Charging
Charged when the asset is powered on
Download Datasheet
